6S 15A 24V Li-ion Lithium Battery BMS Protection Board For 18650 Battery Cells with Cell Balancing - RS1875

Description:

This 24V 6S 15A BMS (Battery Management System) is a crucial protection module designed for 6-cell series lithium-ion (Li-ion) battery packs. It provides comprehensive safety features to extend the lifespan and ensure the safe operation of your battery. With a continuous discharge current of 15A, this BMS is ideal for a wide range of applications, including electric bicycles, scooters, power tools, and portable power banks.

Specifications:

• Lamp shift maximum discharge current: 15A
• Instantaneous discharge current: 25A
• Charging voltage: 25.5V
• Charging current: 15A (MAX)
• Overcharge detection voltage: 4.28 ± 0.05V
• Overcharge protection delay: 0.1S
• Overcharge release voltage: 4.08 ± 0.05V
• Over discharge detection voltage: 2.55 ± 0.08V
• Over discharge detection delay: 0.1S
• Over discharge release voltage: 2.9 ± 0.1V
• Overcurrent detection voltage: 150mV
• Overcurrent detection delay: 9MS
• Overcurrent protection current: 30 ± 3A
• Overcurrent protection release condition: Disconnect the load
• Short circuit detection delay: 250uS
• Short circuit protection Release condition: disconnect the negative open
• Main circuit conduction resistance: ≤20mΩ
• Working current: ≤30uA
• Sleep current (battery over-discharge) ≤10uA
• Temperature range: -30 / + 80°C

Features:

• A 24V 6S 15A BMS Board has fine workmanship and is durable.
• A 24V 6S 15A BMS Board is for the rechargeable (generally refers to the lithium battery), providing protection for the integrated 24V 6S 15A BMS Board. A lithium battery (rechargeable type) needs protection.

Package Included:

1 x 24V 6S 15A BMS Board
