The Johnson Geared Motor gives very good torque at an affordable price hence they are widely applicable in Pan/Tilt camera, auto shutter, welding machines, water meter IC card, grill, oven, cleaning machine garbage disposers, household appliances, slot machines, money detector, automatic actuator, coffee machine, towel disposal, lighting coin refund devices, the peristaltic pump and so on. Also, they are best suitable with highly developing capable robots or robotic platform, various automation purposes.
- Operating Voltage(VDC) : 6 to 18
- Rated RPM : 60
- Load Current(A) : 1.1
- 60RPM 12V DC geared motors for robotics applications.
- It gives a massive torque of 10Kgcm.
- The motor comes with metal gearbox and off-centered shaft.
Description:
Features:
- 10RPM 12V DC motors with Metal Gearbox
- 18000 RPM base motor
- 6mm shaft diameter
- Gearbox diameter 37 mm.
- Motor Diameter 28.5 mm
- Length 63 mm without shaft
- Shaft length 15mm
- 300gm weight
- 10kgcm torque
- No-load current = mA(Max), Load current = upto 9.5 A(Max)
Specification:
| Base Motor RPM | 18000 |
| Gear Material | Metal |
| Rated RPM | 60 |
| Operating Voltage | 6 to 18V DC |
| Nominal Voltage | 12V |
| Rated Torque | 11.7 kg-cm |
| Stall Torque | 46 |
| No-Load Current | 300 mA |
| Load Current | 900 mA |
| Shaft Diameter | 6 mm |
| Shaft Length | 25 mm |
| Gearbox Diameter | 37 mm |
| Motor Diameter | 27 mm |
| Motor Length | 68 mm |
Dimensions:
Package Included:
1 x 60 RPM Johnson Geared Motor High Torque Motor
