- Model : HX-4S-A01
- Charging voltage : 16.8V-17V
- Overvoltage range : 2.3~3.0V±0.05V
- Upper working current : 8 to 10A
- Internal resistance : less than 100mΩ
- Effective life : more than 50,000 hours
Description :
This 4S 14.8V 10A Lithium battery Protection Board comes with over-charge, over-discharge, over-current and short circuit protection, for a variety of various shapes 3.7V lithium-Ion batteries. HX-4S-A01 is Small size, suitable for many requirements of high integration, low cost of the occasion, to meet a wide range of performance requirements to ensure that the battery pack is absolutely safe and reliable.
Application:
- Small power inverter
- Massager battery pack
- LED lamp backup power
- Electronic products
- Solar street lamp battery pack
- Monitoring standby power supply.
Feature:
- This protection board is suitable for 4 series Li-ion cell.
- Adopt a precision integrated circuit for fast and safe charging.
- Support overcharge protection, over-discharge protection, and short circuit protection.
- This product has gone through load and ageing test for quality assurance.
Specification:
- Model : HX-4S-A01
- Charging voltage : 16.8V-17V
- Overvoltage range : 2.3~3.0V±0.05V
- Upper working current : 8 to 10A
- Internal resistance : less than 100mΩ
- Effective life : more than 50,000 hours
Package Included:
1 x 4S 10A 18650 Lithium Battery Protection Board
