315/433MHz 220V 10A Wireless RF Remote Control Switch 1-Channel Relay Receiver For Home Automation And Electrical Devices - RS2511

Description:

This versatile 1-Channel Wireless Relay Remote Control Switch Receiver is an ideal solution for automating a wide range of electrical devices in your home, workshop, or garage. Operating at either 315MHz or 433MHz, this high-performance RF receiver provides a reliable and long-range wireless connection, allowing you to control lights, motors, garage doors, and other appliances from a distance.

Designed for demanding applications, the receiver module features a robust 220V AC input and a 10A relay output, capable of handling significant power loads. This makes it perfect for controlling heavy-duty equipment without the need for a complex and costly wiring setup. The superheterodyne receiver boasts a high sensitivity of -107dBm, ensuring stable performance and an impressive remote control distance of over 100 meters in an open environment.

Specifications:

• Input Voltage: AC85V-AC220V
• RF Working Mode: Super Heterodyne Receiver
• RF Frequency: 315/433MHZ
• Remote Control Distance: >100 meter(In open environment)
• Receiver Sensitivity: -107dBm
• Decoding Way: MCU Software decoding

• Channel: 1
• Multiple working Modes: Jog/Non-Latched,inter-lock/Latched,self-lock /Self-Latched

Features:

• Operate devices remotely using a radio frequency (RF) signal.
• The 10A relay can handle devices up to 220V, making it suitable for a wide range of applications, including lights, motors, and appliances.
• Controls a single device or circuit.
• Supports both 315MHz and 433MHz frequencies, allowing for compatibility with a variety of remote controls.
• A simple pairing process between the receiver and the remote control.
• Small form factor for easy installation in junction boxes or device housings.

Package Included:

1 x 315/433MHz 220V 10A Wireless RF Remote Control Switch
