Description:
18650 BMS 4S 40A Li-ion Battery Charger PCB though have high energy density and are light in weight, are very dangerous if abused i.e. if you overcharge or undercharge the battery or draw more current than it can provide then it can explode damaging the surroundings or even potentially harm the humans around. To prevent this from happening you should use your batteries with a protection board.
This 4S 40A Lithium-ion Battery Protection Board monitor protects three cells connected in series by monitoring the voltage and current in and out of the battery pack and if any unsafe condition happens then it will cut off the battery from the load or the charger. This can be used in any DIY project with low current like Arduino or Raspberry Pi-based projects, 3D printers, Quadcopters, Robotics applications, etc. As it can handle currents up to 40A you can also use it in slightly higher currents. This Board is suitable for 18650 cells having a nominal voltage of 3.6V or 3.7V, so it can provide a nominal voltage of about 14V and a maximum voltage of 16.8V.
Specifications:
- Colour: Green
- Number Of Memory Sticks: 1
- Item Weight: 150 g
- Voltage: 14.8 Volts, 16.8 Volts
- Included Components : 18650 BMS 4S 40A Li-ion Lithium Battery Charger
Features:
- The 4-string 40A lithium battery protection board comes with an automatic recovery-recovery function.
- The equalization version (balanced version) applies to electric drills with a starting current below 80A and power below 230W.
- The new upgraded balance version 4S40A BMS PCB increased the anti-interference function, reduced the current large heat by 30%, and increased the starting power from 135W to 220W.
- 10 imported low internal resistance MOS tubes, continuous discharge 40A, equalization current 100mA, suitable for electric drills, sprayers, LED lights, low-power inverters, etc.
- 18650 BMS PCB Protection Board with 40A Li-ion Battery Charger Ideal for Drill Motor 14.8V 16.8V Lipo Cell Module.
Package Included:
1 x 18650 BMS 4S 40A Li-ion Battery Charger Standard Version PCB 4S 40A Li-ion Battery Protection Board With Balance Li-ion Battery Charger And Protection Board For Drill Motors Powerful 40A Li-ion Battery Management System For Drills
