Description:
This 12V 500MM Linear Actuator with Stroke Lengths 150MM, 5mm/S, 6000N, and 12V is an electric push rod and an ideal solution for industrial, agricultural machinery, construction, clean sweeping vehicles, vessels, cargo and many other applications.
12V 500mm Stroke 6000N Linear Actuator used in various simple or complex processes as executive machinery to realize remote control, centralized control, or automatic control. The electric push rod is composed of the drive motor, reduction gear, screw, nut, guide sleeve, pushrod, sliding seat, shell, micro-motion control switch, etc. With Reliable performance, sensitive action stable running.
Specifications:
- Operating Voltage (VDC): 12
- Stroke Length (mm): 500
- Force (N): 6000
- Speed (mm/s): 5
- Cable Length (cm): 50
- Mounting Hole Diameter (mm): 10
- Motor diameter (mm): 65
- Protection level: IP54
- Speed at Full Load (mm/Sec): 5
- Speed at No Load (mm/Sec): 7
- Self-Locking Force (N): 6000
- Noise Level (dB): <40
Features:
- Aluminium frame and extension tube
- Compact Design
- Built-in Limit Switch
- Low Noise
- Moisture-proof Surface
- Long life: The drive motor adopts a new carbon brush structure, with a service life of more than 50000 times.
- Permanent magnet DC motor drive: Voltage 12VDC
- Self-Locking Force: 6000N
Applications:
- Autos, solar tracking system, agricultural machinery, the wedding system, industrial electric lifting system
- The medical electric bed, surgical bed, traction bed
- Electric equipment: Electric sofa, Electric lifting lever, Electric booth, electric sunroof, etc;
- Chair for medical use: Electric wheelchair, massage chair, dental chair.
- Product Applications: TV lift tables, massage beds, electric beds, medical chairs, electric equipment, micro-devices, electric sofas, camera frames, cameras, and more
Package Included:
1 x 12V 500MM Linear Actuator
