Description:
Realize the 12V 1 Channel Bluetooth Relay Module of mobile phone, switch on and off anytime and anywhere, In the open environment, the maximum stable transmission distance of the mobile phone when it is carried on the Bluetooth module is 10m.
Two types of APP are optional, which can be downloaded and controlled wirelessly, and are dedicated to Bluetooth relay; The General APP is downloaded from Android App Mall, Mobile APP is connected to Bluetooth control. Mobile apps are easy to configure and operate.
On-board 8-circuit 12V, 10A/250V AC 10A/30V DC relay, capable of continuous closing for 100000 times, with diode leakage protection and short response time
Basic Instruction:
Install the Android APP ‘Bluespp.apk’ after the connection is correct, search for the Bluetooth device and connect it. The pairing password is 1234, input the name and content of the instruction (A00101A2 open relay instruction: the content is A00100A1 close relay), and select send in hexadecimal form.
Specification:
| No. of Channels: |
1 |
|---|---|
| Operating Voltage (VDC) |
12 |
| Onboard |
N76E003/STM8S003 and SPP-C Bluetooth 2.1 module |
| Control Distance |
10m (on open area) |
Features:
- Effective control distance(on open area): 10m
- Easy to set up and pair with Android Phone
- Onboard Bluetooth status indicator and relay indicator
- With 2 optocoupler isolation, strong anti-interference ability
- Onboard N76E003/STM8S003 and SPP-C Bluetooth 2.1 module
- Module Operating Voltage: 12VDC
- On-board 12V, 10 A / 250 v AC 10 A / 30 v DC relay, absorb 100000 times continuously.
- Module with diode effusion protection short response time
LED Indications:
LED D1(Blue): Bluetooth state indicator -
- D1 blink slowly-Search Module over Bluetooth and wait till pairing
- D1 Continue ON means a connection established and ready to use
LED D2 (Red): Relay indicator -
- These LEDs will show the status of Relay ON-OFF individually
Package Included:
1 x DC 12V 1 Channel Bluetooth Wireless Control Relay Module
