Description:
11.1V 2200mAh Lipo Battery, polymer lithium-ion or more commonly lithium polymer batteries (abbreviated Li-poly, Li-Pol, LiPo, LIP, PLI or LiP) are rechargeable (secondary cell). 11.1V 2200mAh Lipo Battery is usually composed of several identical secondary cells parallel to increase the discharge current capability, and are often available in series to increase the total available voltage.
Li-ion cells are based on intercalation compounds. The compounds are materials with a layered crystalline structure that allows lithium ions to migrate from or reside between the layers. During the discharge of an 11.1V 2200mAh Lipo Battery, ions move from the negative electrode through an electrolyte to the positive electrode, causing electrons to move in the opposite direction around the circuit to power the load.
Once the ions in the negative electrode are used up, the current stops flowing. Charging the 11.1V 2200mAh Lipo Battery forces the ions to move back across the electrolyte and embed themselves in the negative electrode ready for the next discharge cycle.
Specifications:
- Volts: 11.1v
- Capacity: 2200mAh
- Cell Configuration: 3S1P
- Continuous Discharge: 25C
- Max Burst Rate: 60C
- Max Volts per Cell: 4.2V
- Charge Rate: 1C
- Wire Gauge: 12 AWG Soft and Flexible Low Resistance Silicone Wire
- Plug Type: T
Features:
- This battery is a rechargeable battery which uses Lithium Ion Technology.
- This LiPo Battery pack is specifically manufactured to power quadcopters and multi-rotors.
- 11.1V 2200mAh Lipo Battery delivers full-rated power and offers great performance and flight times.
Package Included:
1 x 11.1V 2200mAh Lipo Battery 11.1V 2200mAh 3S 25C Lithium Polymer Battery
