Description:
The 10A Motor Speed Controller allows controlling the direction of a DC motor using a Pulse-Width-Modulated (PWM) DC voltage with a Duty Cycle fully adjustable from 10%-100%. The motor speed controller can provide a continuous current of 8A to your DC motor or other DC load. The 10A Motor Speed Controller also includes a 10A fuse, with the reverse connection of the power supply and control voltage over-voltage protection function.
Specifications:
| Input Supply Voltage |
DC 12V-40V |
| Maximum Output Power |
400W |
| Maximum Continuous Output Current |
8A |
| Static Current |
0.02 A ( Standby ) |
| PWM Frequency |
13kHz |
| PWM Module Type |
PWM 12V-40V 10A |
| Duty Cycle Adjustable |
10%-100% |
| Operation Environment Temperature |
-20-40℃ |
Features:
- Control the speed of a DC motor with this controller
- High efficiency, high torque, low heat generating
- With reverse polarity protection, high current protection
- Low heat generating controls the speed of a DC motor with this controller with reverse polarity protection
- 10A Motor Speed Controller has high current protection working voltage
- You can configure speed with a potentiometer. You can drive a lot of motors as unidirectional
Package Included:
1 x 10A Motor Speed Controller 12V-40V10A DC Motor PWM Speed Control Switch Governor
