Description:
Experience robust and reliable control with this high-performance 1-channel relay module. Designed for demanding applications, it seamlessly integrates a 30A relay capable of switching high-current loads.
The inclusion of an optocoupler provides crucial electrical isolation, enhancing safety and minimizing the risk of interference. This compact and efficient module is an ideal solution for a wide range of industrial and automation projects. It can be used as a single chip module for appliance control and work with both DC or AC signals where you can control the 220V AC load.
Specifications:
- Channel: 1
- Trigger Voltage (VDC): 24
- Switching Voltage (VAC): 250@30A
- Switching Voltage (VDC): 24@30A
Features:
- High-impedance controller pin
- Pull-down circuit for the avoidance of malfunction
- Power supply indicator lamp
- Control indicator lamp
- One normally closed contact and one normally open contact
- Triode drive, increasing relay coil
- With 4 fixed screw holes, a hole diameter of 3.1mm, convenient installation, and fixation
Note:
- On the high level and low level-triggered mode, friends who do not understand, have a look
- High-level trigger refers to the signal voltage between input and trigger, can be understood as a signal input with VCC cathode short-circuit triggered away;
- Low-level trigger refers to the signal voltage between the input terminal and Earth OV trigger, can be understood as a signal input terminal and the GND negative electrode short circuit triggered is a way 1-channel relay module connection.
Package Included:
1 x 1 channel 24V 30A Relay Control Board Module with Optocoupler
