- AC Input: AC85-265V (Global common)
- AC Frequency: 50HZ/60HZ
- Output Voltage: 12V
- Output Current: 6A-8A
Description:
The power module exclusive use of double-sided PCB design, performance is more stable, more reliable, more suitable for industrial control system power supply. The decoder board is of dual-channel audio output without amplifier, suitable for devices which have amplifier. The decoder board is of FM radio function, allowing you to listen to the local FM radio after connected to the antenna.
Specification:
- AC Input: AC85-265V (Global common)
- AC Frequency: 50HZ/60HZ
- Output Voltage: 12V
- Output Current: 6A-8A
- Output Power: 0W
- Modulation: Pulse width modulation
Features:
- Dual decoding supports MP3 / WMA / WAV / APE lossless format music
- Support Bluetooth function, Bluetooth version 5.0
- With digital tube display
- Compatible with MMC / SD / MMA and other cards, Compatible with USB interface (U disk)
- Power failure memory function
- Supports 5-10 meters away infrared remote control operation
- Supports external audio input (AUX)
- Compatible with FM radio, receiving frequency band (87.5MHZ-108.0MHZ)
- Button: four-button multi-directional control, MODE / previous song / play / Pause / next song
Button Operation Details:
- Previous button (VOLUME down): Short press on the MP3 status for the previous song, long press to decrease the volume; short press on the FM state to adjust the station number; short press below Bluetooth function is a song, long press to reduce volume.
- Play / pause: short press on the MP3 status to play / pause; short press on FM status to Play / Pause, long press to automatically receive and save the station; short press to play / Pause under Bluetooth function.
- The next song button (volume increase): short press on the MP3 status for the next song, press and hold to increase the volume; short press on the FM state to set a station number; short press below next song of Bluetooth function, long press to decrease volume.
- Mode button: Switch between USB / SD / FM / AUX / Bluetooth function.
Package Included:
1 x MP3 Decoder,DC12V Bluetooth MP3 Decoder Board Audio Module USB SD TF FM Radio Lossless WMA/WAV
