Description:
The Raspberry Pi Compute Module 5 IO Board is your go-to for integrating the Raspberry Pi Compute Module 5 into products. It also serves as a robust, industrial-grade Raspberry Pi alternative, providing a powerful starting point for development.
This IO board breaks out all Compute Module 5 peripheral interfaces to standard Raspberry Pi 5 connectors (including full-size HDMI), letting design engineers fully utilize our flagship modular product's capabilities. It even features the famous power button for easy control.
The IO Board works with all Compute Module 5 parts, giving you full flexibility. Even better, it's available as a KiCad reference design, perfect for kickstarting your custom projects.
Specifications:
| Connectivity | Standard 40-pin GPIO header Gigabit Ethernet RJ45 with PoE+ HAT+ support1 2 × USB 3 sockets microSD card socket for Compute Module 5 Lite modules M.2 M key PCIe socket 4-pin fan connector 2 × MIPI DSI/CSI-2 FPC connectors (22-pin 0.5 mm pitch cable) Raspberry Pi HAT+ connector RTC battery socket |
| Video | 2 × full-size HDMI 2.0 connectors |
| Input power | External +5V USB-C PSU Power button to wake and shut down Compute Module 5 |
Features:
- 160 mm × 90 mm form factor
- Standard 40-pin GPIO header
- Gigabit Ethernet RJ45 with PoE+ HAT+ support
- 2 × USB 3 sockets
- microSD card socket for CM5 Lite modules
- M.2 M key PCIe socket
- 4-pin fan connector
- 2 × MIPI DSI/CSI-2 FPC connectors (22-pin 0.5 mm pitch cable)
- Raspberry Pi HAT+ connector
- RTC battery socket
- 2 × full-size HDMI 2.0 connectors
- External +5V USB-C PSU
Useful Links:
- Raspberry Pi Compute Module 5 IO Board product brief
- Raspberry Pi Compute Module 5 IO Board datasheet
- Raspberry Pi Compute Module 5 IO Board design files
Package Included:
1 x Raspberry Pi Compute Module 5 IO Board
