MAX7219 Dot Led Matrix Module 8×8 MCU Control Display Module For Arduino ARM Rasberry - AA086

MAX7219 Dot Led Matrix Module 8×8 MCU Control Display Module For Arduino ARM Rasberry - AA086

SKU:AA086

1196 in stock

Regular price Rs. 115.00
Regular price Sale price Rs. 115.00
Sale Sold out
Shipping calculated at checkout.

For refund/return/replacement, call us at +91 95995 94524 , +91 95995 94520 or mail us at support@rees52.com

Delivery Time

  • Delivery time with the Express Shipping option is 2-3 working days, and with the Standard Shipping option is 5-6 working days. It varies based on location, reliant on courier services.

  • Delivery time if the order item is on Preorder Status is 15-20 working days.

COD (Cash on Delivery)

  • For COD you have to pay extra charges of Rs 350/- before the shipment. (We will share the company QR Code, UPI ID or Account details for the same)
View full details

Description:

MAX7219 Dot matrix Modules with input and output interfaces, support for cascading multiple modules. The input-output termination module of the first two modules of the first one, the first two modules of the termination input terminal of the three modules, and so on.

Specifications:

  • Module Operating Voltage: 5V
  • Driver Chip: MAX7219
  • Model Type: LED Dot Matrix Module

Features:

  • Holes with four screws, diameter of 3mm
  • Modules with input and output interfaces, support for cascading multiple modules

Pin Description:

  • VCC: 5V
  • GND: GND
  • DIN: P20
  • CS: P21
  • CLK: P22

Wiring Instructions:

  • On the left block to an input port, an output port on the right
  • When the control of a single module, enters the port receives a CPU
  • When more than 3 modules cascaded output-input termination CPU

Package Included:

1 x MAX7219 Dot Matrix Module
