Description:
The 4-20mA Signal Generator is small and light in weight but has a long standby time and high precision. This signal is commonly used in industrial process control systems to represent the value of a measured variable, such as temperature, pressure, or flow rate.
A 24V current and voltage transmitter calibrator is a specialized tool used to test and calibrate 24V current and voltage transmitters. These transmitters are used to convert physical measurements into electrical signals that can be transmitted to a control system.
Signal sources can be used for a variety of purposes, such as testing electronic components, generating waveforms for analysis, or providing input signals to other devices.
Specifications:
- Material: Plastic
- Active current output: range: 0-24mA; resolution: 0.01mA; maximum load: 750
- Passive current output: range: 0-24mA; resolution: 0.01mA; external power supply up to 30V.
- Voltage output: range: 0-12V; resolution: 0.01V; maximum current 30mA
- 24V voltage output: drive current: 24mA.
- Current input measurement: range: 0-24mA; resolution: 0.01mA; input impedance: 100
- Voltage input measurement: range: 0-30V;
Features:
-
Internal reverse and overcurrent protection with a protection voltage of 30V.
- Charge with a mini USB.
- Multifunction Calibrator is easier for users to operate at night and during the day.
- Built-in battery, coarse and fine adjustment dual mode, adjustment number can be set. and customized quick adjustment modes.
- Store output value when power is turned off.
- Output short circuit protection, reverse protection, and load protection.
Package Included:
1 x 4-20mA Signal Generator Multifunction Calibrator Economy Signal Generator Handheld Signal Generator 24V Current and Voltage Transmitter Calibrator With 0-10V Signal Source For Field Testing and Calibration
